992062 (2552 XL) - Ariens Zoom 52" Zero-Turn Mower, 25hp Kohler (SN: 002501 - 003999) Motors And Wheels Parts Diagram

Zoom 52" Zero-Turn Mower, 25hp Kohler

Motors And Wheels Parts Diagram

  • Title

1

Ariens 09282451

FORK - BLACK
(Superseded to 59208600)

$173.99

$

Usually ships in 4-12 days

0

2

Ariens 69000300

BRG, CONE W/ GREASE
(Superseded to 05406900)

$21.99

$

In Stock, Qty 20+

0

3

Ariens 05407000

BRG-CUP1.980X.420

$19.99

$

In Stock, Qty 19

0

4

Ariens 00531400

BEARING SEAL 1.5 X 2 X .18

$11.99

$

In Stock, Qty 20+

0

5

Ariens 00531500

SPACER 1.005X1.5075X.375

$9.49

$

In Stock, Qty 14

0

6

Ariens 00160900

SPACER, WHEEL

$41.99

$

Usually ships in 4-12 days

0

7

Ariens 06607800

KEY-WDRF .31X1.00 SFT #B

Note: (Included with 13)

$5.49

$

Usually ships in 4-12 days

0

8

Ariens 07147800

WHEEL/TIRE ASM
(Superseded to 59219000)

$206.99

$

In Stock, only 1 left!

0

Ariens 07147100

TIRE, 15X6-6
(Superseded to 07100905)

$79.99

$

In Stock, only 1 left!

0

9

Ariens 05961200

@BLT-HEX .50-13X9.00 GR5 YWZC
(Superseded to 05901930)

$11.99

$

In Stock, Qty 20+

0

10

Ariens 06543600

@NUT-LK-TOP-FLG .50-13 YWZC
(Superseded to 06500907)

$2.49

$

In Stock, Qty 20+

0

11

Ariens 07152300

TIRE/WHEEL ASSY, 23X10.50-12
(Superseded to 59101000)

Note: (062)

$311.99

$

Usually ships in 4-12 days

0

Ariens 07149000

TIRE 23X10.50-12 MULTITRAC C/S

Note: (062, 063)

$

$

Not available

Ariens 07148900

WHL/TIRE 23X10.50-12 MULTITRAC
(Superseded to 07101116)

Note: (062)

$333.99

$

Usually ships in 4-12 days

0

12

Ariens 07067700

BLT, LUG .50-20 X 1.38
(Superseded to 07000143)

$4.99

$

In Stock, Qty 20+

0

13

Ariens 09262800

WHEEL MOTOR, MB15

Note: (includes 18 & 7)

$964.99

$

Usually ships in 4-12 days

0

14

Ariens 05531400

BSHG-SLV .513X.748X2.129

$14.99

$

Usually ships in 4-12 days

0

15

Ariens 09278500

PLATE, MOTOR SUPPORT

$

$

Not available

16

Ariens 07067300

BOLT, WHEEL MOTOR 1/2-13X5.00

$7.99

$

Usually ships in 4-12 days

0

17

Ariens 09247100

HUB & DISK (PARK) 8" 1/2 HOLE

$318.99

$

Usually ships in 4-12 days

0

18

Ariens 06541900

NUT-LK-JAM-PTCH 1.00-20

Note: (Included with 13)

$34.99

$

Usually ships in 4-12 days

0

19

Ariens 06441500

WSHR-FL-STL.755X1.375X.062YWZC
(Superseded to 06401016)

$4.99

$

In Stock, Qty 20+

0

20

Ariens 00595500

NUT, SLOTTED .75-16

$4.99

$

In Stock, Qty 5

0

21

Ariens 06712300

@PIN-CTR .16X1.00 EXTPRSQCT YZ

$2.99

$

In Stock, Qty 12

0

22

Ariens 20655400

CAP,DUST

$11.99

$

In Stock, Qty 20+

0

23

Ariens 05435700

BRG, 25MM ID X 52MM OD X 15MM

$26.99

$

In Stock, Qty 20+

0
